AX PRO wireless alarm system

Issue 3 2021 Perimeter Security, Alarms & Intruder Detection

To help businesses and homeowners boost their security, Hikvision has created its AX Pro wireless alarm system. This includes remote video verification to detect security breaches, secure wireless transmission technology for alarms and video images, and a wide variety of wireless products that trigger alarms rapidly and reliably in the event of a break-in or other security breach. The system also includes the AX Pro hub, which can connect up to 210 detectors to meet customers’ specific security needs.

The range is ideal for home protection and small and medium-sized business applications, supporting ‘simplicity through innovation’ for alarm detection. The system includes five main types of Hikvision AX Pro wireless alarm detectors:

1.) Hikvision AX Pro motion alarm detectors

The AX Pro range offers two types of motion detectors: ‘single-element’ detectors, and ‘dual-tech’ detectors.

Single-element detectors use passive infrared (PIR) or microwave technology to detect moving intruders and to trigger intrusion alarms in real time. Dual-tech solutions combine different technologies, such as PIR, microwave, or cameras to verify intrusion threats and to minimise false positives.

An example of this type of solution is the PIRCAM motion detector, which combines PIR with a smart camera. This solution takes pictures when the PIR sensor is triggered, allowing homeowners or business security teams to verify intrusion incidents remotely.

2.) Hikvision AX Pro glass break detectors

AX Pro glass break detectors work with glass of different types and thicknesses. These detectors can be installed on both walls and ceilings facing glass panels or windows.

The detectors use high-quality broadband microphones to monitor loud high-frequency and low-frequency noises. In a glass breakage scenario, loud, low-frequency sounds are created by shockwaves when a pane of glass is struck (with a heavy object, for example). At the same time, the high-frequency sound confirms that the glass has shattered or broken. This approach to monitoring low- and high-frequency noises ensures that the detectors can distinguish between loud noises in the environment, vibrations caused by high winds, and real glass breakages – helping to minimise false positives.

The AX Pro range includes a single-element glass break detector and a PIR motion detector that includes glass-break detection technology in a single unit.

3.) Hikvision AX Pro door opening detectors

Hikvision door opening detectors comprise two parts: a magnet attached to a door or window, and a second unit attached to the frame. When the door or window opens, the switch is broken and the detector is activated. There are two motion alarm detectors in the AX Pro range. The first is a standard unit that detects door-open ‘gaps’ of up to 43 mm, and a slimline, more discreet unit that detects door-open gaps of up to 53 mm.

4.) Hikvision AX Pro shock detectors

AX Pro shock detectors use high-quality G-sensors to monitor the vibration characteristics of different mounting surfaces, including wooden walls, concrete walls and panes of glass. This allows Hikvision detectors to filter out false positives caused by a number of factors, including small, hard objects hitting a wall; dynamic pressures caused by windy weather; and maintenance teams hammering in nails or conducting other work on a building.

5.) Hikvision AX Pro environmental detectors

The Hikvision AX Pro wireless range also includes additional detectors to improve home and business security. These include both portable and wall-mounted emergency buttons, an EN 14604-certified smoke detector with a 10-year battery life, a water-leak detector and a temperature detector.

Key features of the AX Pro wireless alarm system

• The AX Pro hub which allows 210 detectors to be integrated in a single installation.

• AX Pro Intrusion Verification-as-a-Service (IVaaS) which provides live video verification based on 7 seconds of video recording so users can quickly confirm alarm events on their system.

• Anti-jamming security with signal hopping across up to 50 frequencies to protect the integrity of the system.

• Secure, reliable wireless connectivity with Hikvision’s Tri-X technology, which delivers the highest levels of security and performance.

• Fast, simple installation which requires installers to scan the device QR code and turn on the device, which automatically connects to the control panel.

• Quick, easy configuration via the AX Pro mobile app, web portal and Hik-ProConnect.
